Modern businesses demand simplified, efficient, and secure network architectures. With SD-WAN gaining traction as the go-to solution for cloud connectivity and multi-site networks, managing IP addresses effectively has become critical—especially as public IPv4 addresses remain scarce and expensive.
Nepean Network’s SD-WAN offers a solution that optimises IP usage by reducing the elastic (or floating) IP address requirement to a single /32 address per remote site. This is achieved by leveraging the CPE NAT functionality on the SD-WAN edge, ensuring not only better IP resource management but also an additional layer of cyber protection.
Traditionally, remote sites in WAN architectures required multiple public IP addresses to route traffic to various devices or firewalls. This approach led to:
Excessive IP Consumption: Public IPv4 addresses are limited and costly, especially when multiple addresses are allocated per site.
Complex Configurations: Managing large address spaces across multiple remote locations increases administrative overhead.
Security Risks: Exposing multiple public IP addresses introduces more potential entry points for attackers.
Nepean Network’s SD-WAN simplifies this model by reducing the need for multiple public IPs to a single /32 elastic IP per remote site.
Nepean Network’s SD-WAN edge device acts as a powerful network gateway that efficiently handles Network Address Translation (NAT) for connected devices, including third-party firewalls. The process works as follows:
Private IP Connectivity to the Firewall:
A third-party firewall—whether deployed as an NFV (Network Function Virtualisation) instance or as a physical appliance—connects to the Nepean Network’s SD-WAN edge via a private IP address range. This eliminates the need for the firewall itself to consume a public IP.
NAT at the SD-WAN Edge:
The SD-WAN edge performs NAT, mapping the firewall’s private IP to a single public /32 elastic IP address. All outbound and inbound traffic flows through this elastic IP, ensuring seamless connectivity while conserving valuable IP resources.
Optimised Routing and Control:
The SD-WAN overlay dynamically manages traffic flows, prioritising critical business applications while maintaining secure and efficient routing for all remote site traffic.
Beyond optimising IP usage, Nepean Network’s approach automatically introduces an additional layer of security:
SD-WAN Edge Firewall:
The SD-WAN edge device acts as the first layer of protection, filtering traffic before it reaches the site firewall. Any malicious traffic or unauthorised access attempts are stopped at this point, reducing the load on downstream security appliances.
Third-Party Firewall Security:
The second layer of security is provided by the connected third-party firewall (whether NFV or physical). With its private IP address hidden behind the SD-WAN edge NAT, the firewall remains isolated from direct exposure to the Internet. This dual-layer defence ensures that attackers face multiple barriers before they can reach critical systems.
IP Address Efficiency:
By reducing public IP requirements to a single /32 elastic IP per site, businesses can optimise their IP resources while lowering costs. This is especially valuable for organisations with large-scale, multi-site deployments.
Simplified Network Architecture:
Private IP connectivity to third-party firewalls streamlines configuration and eliminates the need to manage complex public IP address spaces. This simplifies the overall network design.
Enhanced Security:
The dual-layer protection provided by the SD-WAN edge and downstream firewall ensures greater resilience against cyber threats. With the firewall’s private IP hidden from external attackers, the site’s security posture is significantly improved.
Seamless Integration with Existing Firewalls:
Nepean Network’s SD-WAN is vendor-agnostic, supporting both physical and NFV-based third-party firewalls. Businesses can retain their preferred security appliances while benefiting from Nepean Network’s IP and traffic management capabilities.
Reduced Administrative Overhead:
Centralised management of SD-WAN policies, NAT functionality, and IP allocation reduces the operational burden on IT teams, freeing them to focus on strategic initiatives.
Consider a business with 50 remote sites, each requiring robust security and connectivity:
Before Nepan Network’s SD-WAN: Each site consumed multiple public IPs to support direct Internet access, firewalls, and application routing. The result was costly IP overhead, complex configurations, and increased exposure to cyber risks.
After Nepean Network’s SD-WAN: Each site now uses a single /32 elastic IP, with traffic from the third-party firewall (connected via a private IP range) NAT’d at the SD-WAN edge. The business achieves:
A 75% reduction in public IP usage
Simplified network management
Stronger cybersecurity through dual-layer protection
Nepean Network’s SD-WAN solution delivers a smarter, more efficient approach to IP address management by reducing public IP requirements to a single /32 elastic IP per site. Leveraging CPE NAT functionality on the SD-WAN edge, businesses can integrate third-party firewalls seamlessly, optimise underlay resources, and enhance security through dual-layer protection.
In a world where public IPs are scarce, cyber threats are ever-present, and network complexity is increasing, Nepean Network’s SD-WAN ensures businesses can stay connected, secure, and cost-effective—without compromise.
For businesses looking to streamline operations while strengthening their security posture, Nepean Network’s SD-WAN delivers a solution that’s efficient, scalable, and future-proof.
